Vehicle Emissions and Energy Economy information for commercial websites and dealer solutions

VEEEL and safety window labels image API

This JSON-based web service allows you to generate a vehicle emissions and energy economy label for use in a VEEEL-compliant window label when selling a vehicle. You will need to use this as a basis for your labelling solution in order to remain compliant with VEEEL regulation with minimal effort in future.

The web service can be used for server-side processing through a GET or POST, or in browser-based solutions through an Ajax call or similar. It returns two JPEGs (one for VEEEL, one for safety) as base64 encoded strings.

In order to use this service you first need to sign up at https://resources.fuelsaver.govt.nz

Parameters Values Call examples
Request:
api labels
plate [a valid licence plate] - [GNJ454 | FLW415 | HOON] ?params={"api":"labels","plate":"flw415","login":"[]"} Test this call
vin [a valid 17 character VIN] ?params={"api":"labels","vin":""}
chassisnumber [a valid chassis number] ?params={"api":"labels","chassisnumber":""}
modelcode [a valid NZ or Japanese model code] ?params={"api":"labels","modelcode":"300E6H5SP25","modelvariant":"","login":"[]"} Test this call
modelvariant [a valid model variant number (classification number)] - required with a Japanese model code ?params={"api":"labels","modelcode":"ABA-WF0A0D","modelvariant":"3","login":"[]"} Test this call
login [a valid VFEL login token obtained on signup for the VFEL service] Get yours at: https://resources.fuelsaver.govt.nz
Using multiple lookup fields plate=gnj454 will not find a vehicle because it has been de-registered ?params={"api":"labels","plate":"gnj454","login":"[]"} Test this call
Adding the VIN will return the vehicle label ?params={"api":"labels","plate":"gnj454","vin":"WF0MXXGCDM6S47735" "login":"[]"} Test this call
(NZ) modelcode using default list price information for Clean Car ?params={"api":"labels","modelcode":"HA590/590AE/1","modelvariant":"","listingid":"veh_flw415","login":"[]"} Test this call - use a TEST login
CCDpriceEligible overriding default list price information for Clean Car
CCDpriceEligible = [Yes | No | Maybe | blank] 		?params={"api":"labels","modelcode":"HA590/590AE/1","modelvariant":"","listingid":"veh_flw415","CCDpriceEligible":"Yes", "login":"[]"} Test this call - use a TEST login
forceJSONheaders force the API to return Content-Type application/json ?params={"api":"labels","forceJSONheaders":"","plate":"flw415","listingid":"veh_flw415","login":"[]"} Test this call
Sample response:
{
  "status":"ok",
  "message":"found label information",
  "labels":{
    "vfel":"[64 bit encoded image string in JPEG format]"
    "safety":"[64 bit encoded image string in JPEG format]"
  }
}



Example implementation code

Implementation steps for a browser-based solution:

  1. Make an Ajax call to get the information
  2. Inject the data into your web page

jQuery

$.ajax('https://fuelsaver.govt.nz/api/?params={"api":"labels","listingid":"[unique_vehicle_id]","login":"[your_veeel_login]","plate":"flw415"}',
{
type: "GET",
dataType: "json",
success: function (result) {
/*
A successful result object looks like:

An unsuccessfull result might look like:
{"error":"Invalid input parameters"}
or
{"ErrorCode":40,"Explanation":"No valid plate, VIN or other details specified.","LabelID":null,"LabelFormat":"NOVEH","LastRegUpdate":null,"email":"address@email.com"}

*/
if(result.ErrorCode == 0){
$('#your_data_container').html(data_from_webservice);
}else{
$('#your_data_container').html(result.Explanation);
}
},
error: function(xhr, status, the_error){
/* handle the ajax call failing e.g. server 500 errors*/
}
}
});

Plain javascript

var xhr = new XMLHttpRequest();
xhr.onreadystatechange = function() {
if (xhr.readyState === 4){
document.getElementById('your_data_container').innerHTML = data_from_webservice;
}
};
xhr.open('GET', 'https://fuelsaver.govt.nz/api/?params={"api":"labels","listingid":"[unique_vehicle_id]","login":"[your_veeel_login]","plate":"flw415"}');
xhr.send();

Fetch API

var response = await fetch('https://fuelsaver.govt.nz/api/?params={"api":"labels","listingid":"[unique_vehicle_id]","login":"[your_veeel_login]","plate":"flw415"}',{
method: 'GET',
headers: {'Content-Type':'application/json'}
});
response.json();
